1/8'' x 1/2'' Downcut Spiral Endmill - 1/4'' Shank - SRD203

Great for Profiling and cutting out small products and parts. It can be used for pocketing and corners with tight radiuses. I love to use this bit to cut out small parts because the down-cut part of the bit allows the chips to hold the part in place better when cutting.

Recommended Feeds & Speeds

• Hobby CNC with Router - 50 IPM
• Hobby CNC with Spindle - 80 IPM
• Industrial CNC - 100 IPM
• Cut Depth Per Pass - .125"
• RPM's - 18,000
• Plunge Rate = 50% of Feedrate (ex: Feedrate=100 IPM, Plunge Rate=50 IPM)
• These Feedrates are recommended starting points, each CNC is different and feedrates will vary.

Bit Info

• MADE IN THE USA
• Diameter: 1/8''
• Rotation: Downcut
• Cutting Height: 1/2''
• Shank Size: 1/4''
• Flutes: 2
• Overall Length: 2''
• Material: Solid Carbide
• Part #: SRD203
